| Specification | KF1100 Pro | KF1200 Pro |
|---|---|---|
| Operating System | Linux OS | |
| Camera | Dual 2MP Cameras (Visible Light) | |
| CPU / Memory | 1.2GHz Dual Core, 256MB RAM, 512MB ROM | |
| Authentication Method | Face / Card | |
| Face Capacity (Reader Mode) | 3,000 (stored in inBio Pro Plus) | |
| Face Capacity (Standalone) | 1,500 (1:N with DM10) | |
| Card Capacity | 30,000 (1:N with DM10) | |
| Transaction Capacity | 500,000 (Reader Mode) | 100,000 (Standalone) |
| Recognition Speed | < 0.3 seconds | |
| Recognition Distance | 30 cm – 50 cm | |
| Lighting Conditions | ≤ 2,000 lux | |
| FAR / FRR | FAR ≤ 0.01%, FRR ≤ 0.02% | |
| Card Type | ID @ 125kHz (Standard), IC @ 13.56MHz (Optional) | |
| Communication | RS485, TCP/IP, Wi-Fi (Optional) | |
| Power Supply | DC 12V, 3A | |
| Operating Temperature | -10°C to 50°C | |
| Operating Humidity | 10% – 90% RH (non-condensing) | |
| Dimensions (L × W × H) | 91 × 91 × 13.8 mm | 121 × 80 × 13.8 mm |
| Mounting Compatibility | Asian Gang Box | Single Gang Box |
| Housing | Aluminium Alloy | |
| Certifications | ISO14001, ISO9001, CE, FCC, RoHS | |
| Supported Software | ZKBio CVSecurity | |
KF1000 Pro
The KF1000 Pro Series is a compact, dual-mode facial authentication and RFID access control solution. Designed for both RS-485 biometric reader use and standalone operation, it offers powerful facial recognition, RFID card compatibility, and advanced cybersecurity standards.
-
Dual operation modes: biometric reader (RS-485) & standalone (DM10)
-
1,500 face templates / 30,000 cards / 100,000 transactions (Standalone)
-
Facial recognition with <0.3 sec authentication
-
Recognition distance: 30 cm to 50 cm
-
Card types: 125kHz ID (standard), 13.56MHz IC (optional)
-
Advanced algorithm: ZKLiveface 3.5 / 4
-
Compact aluminum alloy housing
-
TCP/IP & optional Wi-Fi communication
-
Compatible with ZKBio CVSecurity software
-
Designed for Asian (KF1100 Pro) and Single (KF1200 Pro) gang box mounting
-
Fully compliant with ZK Cyber Security Base Line (ZKCSBL)
KF1000 Pro Series Spec Sheet: KF1000 Pro Series Datasheet
The KF1000 Pro Series, including the KF1100 Pro and KF1200 Pro, is a powerful and professional-grade visible light facial authentication solution. Designed for flexible deployment, it operates in biometric reader mode (via RS-485 with inBio Pro Plus controllers) and as a standalone access control device (via DM10 module).
The device uses advanced facial recognition algorithms (ZKLiveface 3.5 / 4) with a recognition speed of less than 0.3 seconds and operates effectively within 30–50 cm, even in bright lighting (up to 2,000 lux). It captures and compresses facial templates to just 512 bytes for fast data synchronization with the controller.
In standalone mode, the KF1000 Pro supports up to 1,500 face templates, 30,000 card users, and 100,000 transactions. It also offers flexible TCP/IP and optional Wi-Fi connectivity, a 12V power supply, and is compatible with ZKBio CVSecurity V6.3.0.
With an aluminum alloy casing and wall-mount compatibility for gang boxes (KF1100 Pro: Asian, KF1200 Pro: Single), the KF1000 Pro Series ensures secure, stylish, and efficient biometric access control.
